Weld Positioner




Description

This rotary welding positioner turntable table is crafted from tough cast iron, ensuring long-lasting and reliable performance. Its compact design makes it ideal for installation on various countertops. The turnover mechanism with a self-locking function is both safe and stable, making it easy to use and practical in all situations. It runs smoothly, making it a high-efficiency option for welding work.

61OHLvSYKOL._AC_SL1000_.jpg61CykYP35fL._AC_SL1100_.jpg61-vhAvF53L._AC_SL1000_.jpg61nTgkqlXKL._AC_SL1000_.jpg61Kp8evNJsL._AC_SL1000_.jpg

Details

Power Indicator Light: It can indicate that the machine has been powered on and is working, bringing you more convenience during operation.

Power Cord: The 5.9ft long power cord has sufficient length to facilitate your movement to the desired work position. It can also keep you away from the power supply, making it safer to use.

Large Screws: High-quality large screws can firmly fix the machine and improve the overall stability of the machine.



Application

It can be fixed on the working table or specific tooling for clamping workpiece with manual welding, and can also be used with a welding operation machine to achieve automatic welding, but also for cutting, grinding, assembly, testing, and other processes. It is especially suited for welding flanges, tubes, rounds and other parts up to 22.05 lbs.



Specification

Color: Blue

Model: BY-10

Martial: Cast Iron

Process: Spraying Molding

Plug: US Standard

Input Voltage: AC 110V

Rated Welding Current: 80A

Workbench Rollover: Manual

Rotary Motor Voltage: DC 24V 15W

Rotary Motor Power: 15W

Working Table Speed: 2-10 r/min

Max Speed: 10rpm

Horizontal Loading Capacity: 10kg/22.05lbs

Vertical Loading Capacity: 5kg/11.02lbs

Working Table Tilting Angle: 0-90°

Working Table Diameter: 180mm/7.09inch

Foot Switch Cord Length: 202.5cm/6.64ft

Power Cord Length: 183cm/5.9ft

Product Size: 32*27*28cm/12.6*10.63*11.02inch

Package Size: 35*30.5*34.5cm/ 13.78*12*13.58inch

Net Weight: 8.55kg/18.85lbs

Gross Weight: 9.25kg/20.39lbs


Package Included

1*Rotary Welding Positioner Turntable Table

1*Foot Switch

1*Power Cord

2*Clamping Handles

1*English Manual
