Description

This rotary welding positioner turntable table is crafted from tough cast iron, ensuring long-lasting and reliable performance. Its compact design makes it ideal for installation on various countertops. The turnover mechanism with a self-locking function is both safe and stable, making it easy to use and practical in all situations. It runs smoothly, making it a high-efficiency option for welding work.

Key Features

Build to Last: It is made of high-quality cast iron and adopts spray molding technology, which has good wear resistance and corrosion resistance. You can use it for a long time.

Excellent Performance: It is driven by a 10W high-quality DC motor for smooth and stable operation. With a load capacity of up to 11.02 lbs (vertical) or 22.05 lbs (horizontal), it meets most welding tasks and ensures efficient welding.

Accurate Positioning: The equipped three-jaw welding chuck can prevent the welding parts from moving and falling, making the work more accurate. Moreover, the special anti-electromagnetic interference design effectively reduces the high-frequency interference during TIG welding, which can effectively improve the welding quality.

Adjustable Speed: This machine allows for infinite adjustments of the rotating speed from 2-10rpm through the control knob, making it easy for you to adjust the speed according to different welding processes.

Tiltable Table: It has a table flip angle of 0-90º, which can be fixed at any angle by the knob on the machine to meet a wide range of welding needs.

Flexible Usage: The reserved holes on its base allow you to securely fasten it to most countertops, and the 6.64ft long footswitch plug cord makes it easier to control the machine remotely.

Protective Package: Multiple packaging of sponge, plastic bag and cartons can effectively protect our product in transit.

Guaranteed Customer Service: We aim to provide quality products and services. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.

Details

Power Indicator Light: It can indicate that the machine has been powered on and is working, bringing you more convenience during operation.

Power Cord: The 5.9ft long power cord has sufficient length to facilitate your movement to the desired work position. It can also keep you away from the power supply, making it safer to use.

Large Screws: High-quality large screws can firmly fix the machine and improve the overall stability of the machine.

Application

It can be fixed on the working table or specific tooling for clamping workpiece with manual welding, and can also be used with a welding operation machine to achieve automatic welding, but also for cutting, grinding, assembly, testing, and other processes. It is especially suited for welding flanges, tubes, rounds and other parts up to 22.05 lbs.

Specification

Color: Blue

Model: BY-10

Martial: Cast Iron

Process: Spraying Molding

Plug: US Standard

Input Voltage: AC 110V

Rated Welding Current: 80A

Workbench Rollover: Manual

Rotary Motor Voltage: DC 24V 15W

Rotary Motor Power: 10W

Working Table Speed: 2-10 r/min

Max Speed: 10rpm

Horizontal Loading Capacity: 10kg/22.05lbs

Vertical Loading Capacity: 5kg/11.02lbs

Working Table Tilting Angle: 0-90°

Working Table Diameter: 180mm/7.09inch

Foot Switch Cord Length: 202.5cm/6.64ft

Power Cord Length: 183cm/5.9ft

Product Size: 32*27*28cm/12.6*10.63*11.02inch

Package Size: 35*30.5*34.5cm/ 13.78*12*13.58inch

Net Weight: 8.55kg/18.85lbs

Gross Weight: 9.25kg/20.39lbs

Package Included

1*Rotary Welding Positioner Turntable Table

1*Foot Switch

1*Power Cord

2*Clamping Handles

1*English Manual

Notes

• Please be careful not to be overweight or overloaded.
• Please read the manual and label carefully before using it.
• Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.

6’x6′ Weld Plus Pipe Welding Station – Specifications & Features

• 6’ manual lift from 11” to 103”
• 6’ manual reach from 1/2” to 72” from the center of the mast
• Manual travel car base with v-casters
• Positioner capacity 3,000 lb @ 6” C.G.
• Variable speed table rotation from 0.1 to 1.75 RPM
• 20” self-centering 3 jaw chuck
• Center of the chuck to the floor- 36”
• The Oscillator Dwells 0-9.9 seconds & speed ranges 1 deg to 22.55 deg per second
• 12” of horizontal oscillator adjustment
• 6” of vertical oscillator adjustment
• Ten programmable memory spots
• Two oscillator modes: Standard angular and Step Square Wave
• 6’ remote pendant for oscillation
• 25’ pendant control for part rotation
• 450 amps of DC welding output at 100% duty cycle
• Wire Feed Speed: 50 IPM – 780 IPM
• Processes: Flux Cored, Mig, Pulsed Mig, RMD, Stick, and DC Tig.
• Complete MIG package: Dual wire feeder, 2 ea. MIG guns, ground, cables, and 2 ea. regulator flow-meters
• Input Power: 230/460V 3-PH (Welder), 120V (Positioner)

’x6′ Weld Plus Pipe Welding Station – Product Description

Multiple complete stations available!

This Weld Plus Pipe Welding Station is a turn-key solution for pipe welding! The positioner is designed to rotate pipe while the torch stand holds a mig gun over the workpiece. In addition, a POPWELD weld oscillator manipulates the mig gun to assist with fill passes on the pipe. The POPWELD Pipeworx 400 is designed exclusively for pipe fabrication. Furthermore, A POPWELD ROI allows the operator to adjust weld parameters from a safe distance. In conclusion, this Pipe Welding Station is a must-have for any pipe fabricator!

Track Torch Gas Pipe Cutting Straight Linear Gas Cutting Machine Efficient Gas Cutting Portable Flame Cutting Track Torch Cutter(Acetylene + Oxygen), Three of 70cm Tracks

• This torch track gas cutter machine is made of high quality aluminum alloy, precision craft, great walking stability, and is a portable and lightweight as an ideal portable machine. This track gas cutting can work with acetylene(Note: the machine could also be fitted with a CO3 cutting nozzle for propane gas cutting), and the user can replace the cutting tips as required. （PLEASE NOTE: Do not open the oxygen valve too large, and work with the industrial pressure gauge.）
• TECH PARAMETERS: Thickness of steel plate cutting: 8-100mm; Regulating range: 50-750mm/min(stepless speed regulating); Diameter of circumference for cutting: Φ220-Φ2000mm; Input voltage: AC 110V 50HZ.. Please Note: Connector type: M16, and the air tube size: inner diameter 6mm, outer diameter 12mm
• EASY to USE: The CG1-30 track torch gas pipe cutting come with three of 70cm tracks. Besides, the guide rails provide interface ends for the extended track. The user can according to your needs to connect the guide rail. This machine comes with a detailed manual and you can refer to it when using this product.
• MULTIPLE FUNCTION: The Gas cutter machine can cut steel plates with a thickness of over 8mm. The machine also deals with circular cutting with the specification over Φ200mm, miter cutting, and V-shaped cutting. Besides, processes like flame hardening and plastic welding are also available with the auxiliary devices and the machine's independent power supply
• WIDE APPLICATION: This Pipe Beveling Machine is suitable for petroleum, chemical, mechanical, processing, electricity, construction, mining industries, etc. Also suitable for other large, medium, and small enterprises to cut steel.

Product Description



Introduce:

Our brand is professional industrial equipment manufacturing plant. We had a complete production line and strict product quality control. We focus on research, improvement, and innovation. And We have been immersed in this industry for many years, and with advanced industry standards. Besides, we also produce many kinds of pipe torch gas cutters and welding machines.

CG1-30 Semi-automatic Track Torch Cutting

This torch track gas cutter machine is made of high-quality aluminum alloy, precision craft, and portable lightweight as an ideal portable machine. The motor is directly linked to the gear reducer so as to drive the roller with great walking stability. It's suitable for working outside with convenient and highly effective, indispensable equipment for pipe construction



TECH PARAMETERS: The thickness of steel plate cutting: 8-100mm; Regulating range: 50-750mm/min(stepless speed regulating); Diameter of circumference for cutting: Φ220-Φ2000mm; Input voltage: AC 220V 50HZ. Track length: 70cm Number of tracks: 3	RUGGED BODY: This CG1-30 Semi-automatic Track Torch Cutting is made of alloy-aluminum casting for the machine body, light, splendid figure, precision craft, and sturdy. It is a great ideal for petroleum, chemical, mechanical, processing, electricity, construction, mining industries, etc.	EASY to USE: Please use this machine after carefully reading this operation instruction； The frames provide two types of guide rail: convex and concave. Besides, the guide rails provide interface ends for the extended track. The user can according to your needs to connect the guide rail.	WIDELY USED： This Pipe Beveling Machine is suitable for petroleum, chemical, mechanical, processing, electricity, construction, mining industries, etc. Also suitable for other large, medium, and small enterprises to cut steel. Especially suitable for outdoor work or another place without electricity, indispensable equipment for pipe construction.



Welding Positioner Turntable with 200mm Chuck & Foot Switch, 30KG 220V Rotary Welding Positioner Turntable Table 0-90o Welding Positioner Positioning Turntable 15RPM 310mm

• Smooth Rotation: This rotary welding positioner is driven by an 80W powerful motor, making it rotate smoothly and stably. Made of stainless steel and possessing good hardness and high strength. (horizontal/vertical loading capacity: 66lb/33lb). Get ready to easily rotate your project and get it set in the perfect position.
• 0-90º Tiltable Function: The worktable can be turned instantly between 0-90°. The turning structure of the worm and gear can be self-locked, ensuring it stays fixed at any angle you want. Chuck diameter: 12"/31 cm; Table Height: 15"/38 cm.
• High Quality Three-jaw Welding Chuck: The three jaws are reinforced, preventing the weldment pieces from moving and falling. With three jaws and a welding gun support, the table can clamp any workpiece for manual welding. High quality materials are used, so your projects can be completed at the highest standard.
• Stepless Speed Control: There is a foot switch provided for simple control of the table's 360 degrees rotation. Also, the speed can be regulated by the knob on the machine (stepless speed regulation: 1 - 15r/min).
• Extensive Applications: Especially suitable for flange, steel pipe, and other seam welding. It can be used for annular welding, cutting, polishing, and so on. Also perfect for grinding, testing, assembling and other processes. Use our position with confidence and get your projects requirements met at all times.

Turning Rolls Linkage Roller 1000KG/2205LBS Loading Welding Turning Roll

• Enhance Welding Efficiency: VEVOR turning rolls linkage roller boasts 600w high-torque motor that runs at high speed, providing 2205 lbs / 1000kg strong loading and 80-1600mm/min speed adjustment. It offers exceptional stability and effortless support and rotation of large workpieces.
• Handle Different Sized Workpiece: The 9.84-inch large PU roller comes with inner and outer holes, offering flexibility to adjust the roller gap for different workpiece sizes. The inner holes suit 25-800mm O.D. workpieces, and the outer holes are ideal for 600-1400mm O.D. workpieces.
• Sturdy & Stable Construction: Our welding turning roll has a rugged carbon steel construction for high load capacity and longtime use. High quality wear-resistant PU rollers offer greater friction and more stable support for workpiece. Also includes a welding torch stand to secure the welding gun in place.
• 2 Control Modes, Easy to Operate: The rotary turning rolls comes with a manual control box and a foot switch: 1. Select the auto mode, then the rollers will keep rotating at the set speed; 2. Select the foot mode, through the foot switch, the rollers can rotate in a small range, so that the workpiece can move slightly or fine-tune.
• Versatile Applications: Our rotary welding positioner finds utility across a wide spectrum of industries and applications, including tank manufacturing, bridge construction, pipe welding, and more. It provides essential support for a diverse welding tasks, making it an ideal choice for welding professionals.

Welding Carriage
Programmable
Low Voltage
All Position
Variable Speed

The welding carriage is used throughout the world to automate a wide variety of welding and cutting operations. It is a rugged, reliable precision welding and cutting travel carriage designed for use on rigid track which enables it to operate along any plane. The rigid track can be used in straight sections or be formed for use on curved surfaces. Gullco manufactures several systems and accessories designed for use with the making it one of the most versatile pieces of welding and cutting automation equipment available in the industry.

The carriage is used throughout the world to automate and improve the quality and efficiency of single or multiple arc welding or cutting operations. Welding guns or cutting torches mounted on the carriage move along track at precisely controlled speeds along the desired path in forward or reverse direction. carriage enables welding guns or cutting torches to operate with precise motion from start to finish regardless of the number of passes or the work pieces involved. By adopting this automation great improvements to the quality, efficiency and repeatability of the process are achieved. Poor or awkward accessibility, operator fatigue, or inconsistent workmanship are eliminated.

This unit is designed for operation on flat or curved surfaces as the track can be used in straight sections or formed to follow the contour of the workpiece. The self-aligning wheel system of the carriage grips the top and bottom of the track, enabling it to travel along any plane. The adjustable wheel assembly keeps the carriage snug to the track, while allowing it to be easily mounted and removed from the track at any point. The positive drive of  is obtained from a uniquely designed rack and pinion system, driven by a low voltage permanent magnet motor and gear-head power unit assembly.

• Ideal for automatic horizontal fillet, lap and butt welding operations
• Controls are available to perform continuous and/or stitch weld operations
• Dual gun holder assembly is available for efficient simultaneous welding
• Wheels on the standard Moggy can be reversed to allow the moggy to run on standard v-groove track
• The magnetic moggy has a magnetic base that clings to the vertical member for out of position applications

Automated Trackless Welding Carriage

The  friction drive travel carriage is designed to perform Horizontal Fillet Welding, Lap Welding and Butt Welding. It can be fitted with a Gullco Compact Oscillator to perform multi-pass welding. These operations can be performed on horizontal fillets with a minimum radius of 39 in. (1 meter) and up to a 30º incline. Following is a brief description of the Moggy and components that make up the system.

It is a lightweight, portable, four wheel friction drive travel carriage that can be used with or without track to automate welding operations. A speed potentiometer provides infinite speed selection within the 3.25-100.50 in/min (8.26-255.27 cm/min) range. The unit comes complete with adjustable guide rolls, travel limit switch assembly, vertical and horizontal slides providing 1 3/4" (44.4mm) adjustment and a semi-automatic gun holder. It is designed to run on a horizontal path against a vertical surface or a vertical path against a horizontal surface (Magnetic ) to perform a fillet weld.

The Standard welding carriage can be adapted for use on standard 6" (152.4mm) v-groove track by reversing the wheel assemblies. Safety is assured by using Gullco low voltage 24 volt DC highly advanced control power supply system that is available in 3 line voltage inputs ... 42, 115 and 230 volt AC 50/60 Hz.

Trackless Magnetic Trackless Welding Travel Carriage

"low cost, highly efficient automation of out-of-position fillet, lap and butt welding applications"

This Magnetic is essentially the same as the Standard described inside this folder except it has a magnetic base and heavy duty urethane 0.875" (22.23 mm) wide wheels for continuous travel in the horizontal and vertical position.

Cutting Machine

NO ELECTRICITY, NO PROBLEM.

Quickly Adapt To Your Workpiece.

INTERLOCKING CHAIN MECHANISM

Allows for easy addition or removal of links, accommodating pipes of different sizes.

Standard chain can fit diameters ranging from 114-600mm (4-24in.). Additional links can be purchased for further pipe accomodation.

Controlled Movement At Your Fingertips.

WORM GEAR DRIVE

Though manually operated, the Picle 1-II is equipped with a low gear
ratio, ensuring exceptionally smooth movement for controlled cuts
during operation.

Work Anywhere Without Limitation.

COMPLETELY MANUAL OPERATION

Manual hand crank eliminates the need for power or electricity,
making it an ideal solution for field use.

Additionally, lack electrical components permits low maintenance and repair.

OPTIONAL SNAP VALVE

Provides a convenient one-touch on/off gas valve feature.
